Round Tower Design In the appearance design of this charging pile project, comprehensive consideration from many aspects, the following are some design points:
Clear design positioning
1. Use scenario: This charging pile is mainly installed in the expressway service area, with large traffic flow and quick energy replenishment, so we adopt a tough and practical industrial design style.
2. Target users: This charging pile is positioned for high-end electric vehicle users. We reflect the quality and sense of technology in terms of material, technology and design, and adopt unique color matching, modeling and material to enhance the overall aesthetic feeling of the place.
Focus on functional design
1. Charging port design: The charging port is clearly visible and clearly marked, which is convenient for users to quickly connect the charging cable. At the same time, taking into account different types of charging interfaces, we have carried out a reasonable layout to ensure compatibility.
2. Heat dissipation design: For charging piles with high power, a good heat dissipation system is essential. By designing heat dissipation holes, heat sinks or using intelligent temperature control fans, we ensure that the equipment can effectively dissipate heat and maintain stable performance during long-term operation.
3. Cable management: The main charging pile is designed with a hidden cable management system to avoid messy exposure of cables, which not only ensures the safety during use, but also makes the overall appearance cleaner and more beautiful.
Consider safety and durability
1. Material selection: We use fire-proof, explosion-proof, corrosion-resistant, weather-resistant aluminum alloy combined with new composite materials to ensure that the charging pile can be used stably for a long time in various harsh environments and ensure the safety of users.
2. Structural design: The structure of this charging pile is stable, with sufficient windproof, rainproof, dustproof and impact resistance.
3. Protection design: charging interface and operation panel and other parts are done waterproof, dustproof treatment. By installing waterproof rubber ring, sealing cover, etc., to prevent moisture and dust from entering the inside of the equipment, affecting the normal operation.
Pursuit of aesthetics and easy identification
Overall modeling: the use of multilateral geometric modeling design, so that the charging pile appearance lines smooth, giving a modern, dynamic visual experience; some areas using modular combination, convenient for later maintenance and upgrading, but also to create a unique modeling effect.
Color matching: We decide to use bright colors such as blue and green according to factors such as brand characteristics and use environment. This kind of color symbolizes the concept of clean energy and environmental protection; local matching gray, silver and other neutral colors give people the impression of science and technology and professionalism.
Integration of intelligent elements
1. Display design: The charging pile is equipped with a large screen display to display important information such as charging status, power, cost, remaining charging time, etc. with intuitive graphics and text, so that users can understand the charging situation at any time.
2. Lighting design: We use the top of the charging pile or set around the indicator light, through different colors and flashing frequency to indicate the charging state, while playing a certain role in lighting and beautification.
