Project Name: Beauty washing machine industrial design
Cooperation content: design analysis | appearance design | structural design | prototype production | accompanying running assistance
1. Design Analysis
Use scenario: household bathroom countertop, beauty institution care area; 1-2 times a day, 1-3 min each time.
User group: 18-45-year-old women, focusing on "gentle cleaning, skin care ritual sense, space color value".
Core appeal:
• Deep clean-micro bubble + ultrasonic dual mode, not to hurt the horny;
Elegant integration-with aromatherapy, cosmetics in the same scene display, not abrupt;
Lightweight storage-covers an area of ≤ A5 paper and uses it wirelessly 30 times.
2. Design Language
Shape: chamfered oval "cobblestone" seat, R40mm continuous curved surface, soft but not weak.
Color: ceramic white body + champagne gold waist line, independent but not rigid, with any table does not show cold ice.
Material:
• Shell: high-gloss antibacterial PC, resistant to 75% alcohol wipe;
• Contact: food grade 30 ° soft silicone, face warm.
3. Design Details
Magnetic levitation brush head: annular magnetic attraction, 1 s disassembly and replacement; Bristles 0.05mm DuPont antibacterial wire, sound wave 18 000 rpm.
Hidden water tank: 120 ml removable water tank at the top, the water level can be viewed, and it can be filled for 7 days at a time.
One-key ring light: 2700-6500 K adjustable light on the outer ring of the central metal button, indicating three colors of cleaning/standby/low power.
Wireless seat charging: base Qi 15 W wireless charging, charging when put back, 2 h full power.
Anti-water accumulation: the bottom is inclined at 3 degrees + annular drain tank, and the table top is free of water accumulation and mildew.
4. ergonomics
Grip: body Φ 55mm, weight 185g, female one hand can rotate 360 degrees, wrist load <1 N.
Operating height: when the table is laid flat, the center of the brush head is 35 mm away from the table, and the arm naturally droops without lifting the wrist.
Viewing angle: light + button is centered, and the mirror surface distance is 20cm, which can directly look at the status light.
Cleaning posture: the water tank is magnetically attracted and pulled, and the disassembly and washing are completed for 10 s; The whole machine IPX7 can be washed with water all over the body.
Storage: The wireless base is only 8 mm high, the suction cup is fixed, and it does not occupy an area when hanging on the wall.
Summary
This beauty washing machine upgrades the "facial cleanser" to bathroom art ornaments with soft pebbles and elegant color matching of ceramic and champagne gold. Magnetic levitation brush head, invisible water tank and wireless charging realize 3 seconds to use and 30 seconds to store, truly achieving an elegant cleaning experience of "soft but not weak, independent but not rigid. Design: www.soogot.com
