This product is a car emergency product. Hub-type automobile flood control airbag design, the airbag is composed of four parts, through specially designed screws, the airbag is installed, the airbag is easy to install and disassemble, and the learning cost is low. In the use environment, when the vehicle is parked outdoors, a sudden flood strikes, the water level detection at the wheel hub of the car overflows the warning position, and the car issues an alarm. After a few seconds, the airbag explodes, and the mechanical structure of the hub cover rotates and sticks to the ground. The airbag completely exploded and the inflatable car floated.

25 61

留言板（21）

吴智阳 2022-01-11

If it is designed on the wheel, the airbag will change its orientation with the rolling of the wheel. After the airbag appears, the tire will not be able to move. If you want to make an additional axle structure to keep the airbag level, the high-speed rotation and speed change of the wheel will play a role in the structure. A challenge, the airbag can only be adjusted to parallel to the ground when the car is stopped, and the vehicle can only drift with the flow as.
Also, it is a bit too difficult for a disc-shaped airbag to become such a regular shape. If you don't do the inflation process, you can also add a picture of the inflation process.
You can also give a simple section of the weight of the vehicle and the required airbag volume, how to float the car to a reasonable height, and if there are many things in it, how many people sit and how the water level changes.
I think it is possible to install the airbag on the edge or simply under it, so that the shape is better designed, and then install a paddle plug-in on the wheel edge (although I feel unable to scratch), but this is a bit boring.
Come on, big brother

158****8579 2020-06-16

The idea is not mature enough! There is still much to be improved!

简小白作者 2020-07-11

Yes, this is a conceptual design that was thought at that time. if you want to realize it, there is still a lot to be improved

我也说一句

xiangbalaomie 2019-02-16

So it's easy to steal a car, isn't it

Lancelot741 2018-11-28

The practicability remains to be discussed. When it is not activated, it will have a great impact on the heat dissipation of the brake. It is a bit of picking up sesame seeds and throwing watermelons, but it is always good to take the first step. Praise you

简小白作者 2018-11-30

Uh-huh, safety does need to be considered, but I think this product plan direction is very feasible.

我也说一句

233 2018-11-28

Need an anchor

简小白作者 2018-11-30

I have considered this before. I have added a kind of anchor or hook fixing device. I have not had a more beautiful plan, so I have not added it for the time being.

我也说一句

禾辰 2018-11-27

Without looking at the title, it feels like an anti-collision airbag.

简小白作者 2018-11-30

Haha, car flood control airbag oh

我也说一句

umi_corn 2018-11-27

Give up, this level of rain will only occur once in many years, and after each such rain, urban drainage will be upgraded to reduce similar disaster losses. And even if it is really flooded, you would rather let the car soak than float up, let a few tons of things no one control their drift, for a while you don't know where to crash how many things, after the water recedes you may have to get the car out of the flower bed, drainage ditch, unless you add an anchor to your airbag, but there is nothing on the main road to hook the anchor. It's better to have more insurance with this spare money.

LIANGJUX 2018-11-27

There is always the first step in anything, but I just didn't find a suitable position.

umi_corn 2018-11-28

On the high speed, the speed of the 60cm diameter wheel is 100 kilometers, and it will rotate 14 times per second. Will it affect the rotation of the wheel, and will it accidentally unfold in case of vibration and cause accidents is also a big problem. Before solving the problem, consider the feasibility first, and spend half a day drawing and PPT. The result will not be realized at all, which is also a blind delay. It is good to have ideas, but it is not good to think far enough.

简小白作者 2018-11-30

This is a portable emergency product. It is very convenient to disassemble and can be completed by one person. It will not take up too much space in the trunk of the car.
