Project Name: Respiratory Health Monitor Design
Cooperation content: design analysis | appearance design | structural design | prototype production | accompanying running assistance
1. Design Analysis
Use scenario: family bedroom, chronic disease management center, health care ward, for chronic obstructive pulmonary disease, sleep apnea and other patients with respiratory rate, heart rate, blood oxygen monitoring.
Core appeal:
• Non-sensitive monitoring-non-contact radar detection, no need to wear electrodes;
• Medical-grade accuracy-respiration rate error ± 1 brpm, real-time exception alarm;
Home integration-looks like "bedside sound", weakening the cold feeling of medical equipment.
2. Design Language
Form: elliptical "cobblestone" horizontal host suspended triangular bracket, symbolizing the flow and ups and downs of "mountains and rivers rhyming.
Color: medical white light gold waist line, conveying "Deschamps" quality and warmth; status lights hidden in the waist line, not dazzling at night.
Material: shell PC ABS antibacterial material, surface 1μm fine bite, alcohol-resistant wipe 10,000 times; Bracket aluminum extruded anode, light weight and corrosion resistance.
3. Design Details
hidden radar window:
• The 60 GHz mmWave radar is placed in the top 0.3mm transparent window with no visible openings and signal attenuation <0.5 dB.
Suspension Triangle Bracket:
The triangular cross-section hem continues the elliptic curve of the main machine, the hem radius is R5 mm, and the vision is light; The bottom is 5 degrees backward, and the radar beam naturally points to the chest.
One-piece fabric mask:
The front is covered with acoustic fabric, taking into account both sound and wave transmission, hiding 4 × 1 W array speakers, and playing sleep aid sounds.
Magnetic power socket:
The 24 V power contact at the bottom is adsorbed in alignment, and the power is connected in 1 s. There is no protruding plug, and the head of the bed does not trip the wire.
Quick Disassemble Dust Filter:
• The dust filter screen is embedded in the rear grid, fixed by magnetic attraction, and replaced in 30 s to ensure the heat dissipation and cleanliness of the radar.
4. ergonomics
Placement height: the bracket is 120 mm high, the radar center is 350 mm from the bed surface, covering the height of 0.8-2.2 m, and the user does not need to adjust the sleeping posture.
Viewing angle: the top OLED micro-screen is tilted at 10 degrees, and the respiration/heart rate value can be checked in bed. No visible strong light, sleep without interference.
Operating force: the whole machine is 420g, holding and moving with one hand; The silicone ring at the bottom is non-slip, and the pushing and pulling force is less than 5 N.
Cleaning posture: oval rounded R30 mm, no cleaning dead angle; The fabric mask is removable and washable, IP22 splash-proof.
Sound feedback: The array speaker has a directivity of 60 °, only the bed area is 50 dB audible, and the accompanying room is not disturbed.
Summary
The respiratory health monitor hides the 60 GHz radar in the "cobblestone" fabric sound, and continues the eastern streamline of "Deschamps Yunxing" with shallow gold hem and suspended triangular bracket. Senseless monitoring, sleep aid sound and magnetic attraction power supply make medical accuracy hidden in bedside ornaments to realize "visible breathing and invisible equipment". SOGOT DESIGN: www.soogot.com
