AC 220VAC2A
DC 30VDC2A4G
Suitable for mobile, Unicom, telecom 4G and mobile, Unicom 3G and 2G grid serial ports
The interface provides special parameter configuration software power supply 12VDC ± 10%
Terminal 5.08mm pitch, M2.5 steel screw, 0.2Nm torque, 0.02 ohms
Contact resistance cable specifications 12AWG ~ 18AWG(3.3~0.83 mm2), stripping length 6.5mm
Working environment temperature:-20~70 C, humidity: 15 ~ 90% RH, no condensation
Storage environment temperature:-30~80 C, humidity: 15 ~ 90% RH, no condensation
Enclosure Protection Class IP42 Reference IEC529-598/GB700-86/GB4208
Refer to UL94 for fire rating V-0 (membrane key is not fireproof)
Electromagnetic compatibility reference GB/T13926,EN61000-6-2,EN61000-6-3
Shell material aluminum alloy (bright silver)
Weight about 150g (overall weight) technical parameters
