NFC9189-70W LED explosion-proof platform lamp maintenance-free LED explosion-proof lamp;
Scope of application;
Used for: fixed lighting in various factories, workshops, stations and other places and large-scale facilities, equipment, devices and other areas. This product is widely used in various ironmaking blast furnace platforms, raw material transportation belt corridors, roadways, continuous casting platforms, mining workshops, equipment areas, etc. for fixed lighting.
Technical parameters;
Implementation standards: GB7000.1-2007, GB4208-2008 and enterprise standards
Input voltage: AC220V
Input frequency: 50Hz
Light source type: LED
Light source power: 70W
Insulation grade: I
Protection grade: IP66
Anticorrosion grade: WF2
Weight: 2.3Kg
Applicable cable specifications: Φ7mm ~ Φ12mm
Size: φ215x220mm
Product introduction;
Accurate ring light distribution design can meet the needs of 360 lighting on site.
The shell is made of high-quality aluminum alloy die-casting and has high forming strength. The surface is sprayed with high-voltage electrostatic powder and is corrosion-resistant.
Brand LED light source is selected, with high luminous efficiency, high color rendering, low light attenuation, low energy consumption, no flicker, long service life, maintenance-free, and no subsequent use cost.
Uniform illumination; The light is soft and there is no glare, which effectively avoids the visual fatigue of the staff.
The integrated design is convenient for on-site installation and maintenance. and simplified field wiring.
installation mode: wall type 30 °(b1); wall type 90 °(b2); ceiling type (x); boom type (g);
Flange type (f); Guardrail type (h); Brace type (z);
