BFC8115A-150WLED explosion-proof floodlight;
Application site:
1. The products are widely used in petroleum, chemical enterprises and other industries. There are explosion-proof zones 2 that burn explosive and dangerous gases. They can provide floodlighting for customers' on-site construction operations at night;
2. The product can be used as road lighting in petroleum, chemical enterprises and other industries with flammable and explosive dangerous gases;
BFC8115A-150WLED explosion-proof floodlight;
Technical parameters:
1. Ambient temperature:-20 ~ +40 ℃
2. Rated voltage: AC220V 50Hz
3. Light source power: 100W 150W
4. Average life: 50000h
5. Lead-in cable: φ8-12mm
6. explosion-proof mark: Ex nR IIC T6 Gc/Ex tD A21 IP65 T95 ℃
7. Protection grade: IP65
8. Anti-corrosion grade: WF2
9. Overall dimensions: 325*240 * 145mm
10. Net weight of product: 7kg
Product characteristics:
Imported LED chips are preferred, which have excellent light flux maintenance rate and high light efficiency. 120WLED explosion-proof lamp adopts surface mount technology SMT to greatly improve thermal conductivity. Carefully design honeycomb light supplement structure to effectively improve the efficiency of the lamp.
It adopts constant current drive and has short circuit and overvoltage protection functions. The 140WLED explosion-proof projection lamp can also be made into LED explosion-proof emergency lighting lamp, which has two working modes of normal lighting and emergency lighting. The battery power supply is automatically converted after power failure, and the emergency time can reach 50 minutes.
80WLED explosion-proof lamp has excellent electromagnetic compatibility and will not cause any interference to other electrical appliances and transmission networks. The power supply itself has excellent anti-electromagnetic interference capability. It has wide voltage compatibility and tolerance 20% voltage fluctuation;
The driving power supply of the 100WLED explosion-proof lamp adopts a waterproof sealing compound design to ensure that the components are not corroded, the power factor is> 0.95, and the use efficiency is more than 90%.
BFC8115A-100WLED explosion-proof floodlight whole lamp adopts IIC explosion-proof structure and IP66 protection grade, which has excellent explosion-proof protection performance. It adopts high borosilicate tempered glass and can withstand high energy impact;
All exposed fasteners and accessories of 150WLED explosion-proof lamp are made of stainless steel with high corrosion resistance. They adopt integrated emergency cavity and do not need to be equipped with another emergency box, which is convenient for square installation and maintenance;
The top cavity is used to open the cover, which is convenient for users to connect and maintain. A variety of installation methods can be selected by users.
Note: The color of the product is normally gray, or it can be made brown or yellow.
